PLEASE NOTE: BOARD SHIPS WITH HEADER PIN BLOCKS (UNATTACHED) / FLASHED WITH LED STRIP CONTROL SOFTWARE.
Teensy 3.2 is the heart of addressable LED strip control in Virtual Pinball applications using DOF
(Directoutput Framework) by SwissLizard and later ported to DOF R3++ grand unified by MJR.
This is a small, breadboard‐friendly development board designed by Paul Stoffregen and PJRC.
Bringing a low‐cost 32 bit ARM Cortex‐M4 platform to hobbyists, students and engineers,
using an adapted version of the Arduino IDE (Teensyduino) or programming directly in C language.
An upgrade over 3.1! Teensy 3.2 is a drop‐in replacement upgrade for 3.1 and can run any
sketches designed for 3.1.
This latest version of this complete USB‐based microcontoller development system now adds a more
powerful 3.3V regulator, as well as accepts a wider voltage input range. This board has the same size,
shape and pinout as well as full compatibility with all shields and add‐on boards made for the Teensy
3.1, plus double the Flash memory as the Teensy 3.0.
